Product Description

The TL-SG1008MP is an 8-Port Gigabit Desktop Switch with all 8 ports supporting the PoE+ standard. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable. With a total power budget of 126W, up to 30W per port, TL-SG1008MP can power more high-powered devices such as wireless Access Points (APs), IP Cameras or IP Phones. Moreover, with innovative energy-efficient technology, the TL-SG1008MP can save up to 75% of the power consumption, making it an eco-friendly solution for your business network.



HARDWARE FEATURES
Interface
  • 8 10/100/1000Mbps RJ45 Ports
  • AUTO Negotiation/AUTO MDI/MDIX
Network Media
  • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
  • 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
  • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity
  • 1
Physical Security Lock
  • No
Power Supply
  • 100-240VAC, 50/60Hz
PoE+ Ports(RJ45)
  • Standard: 802.3at/af compliant
  • PoE+ Ports: 8 Ports
  • Power Supply: 126W
Mac Address Table
  • 4K
Buffer Size
  • 1.5Mbits
Switching Capacity
  • 16Gbps
Dimensions ( W x D x H )
  • 11.6 × 7.1 × 1.7 in.
  • (294 × 180 × 44 mm)
Mounting
  • Desktop/Rack Mountable
Max Power Consumption
  • 9.89W(220V/50Hz. no PD connected)
  • 140.67W(110V/60Hz. with 126W PD connected)
Max Heat Dissipation
  • 33.74BTU/h(no PD connected)
  • 492.56BTU/h(with 126W PD connected)



SOFTWARE FEATURES
Advanced Features
  • Compatible With IEEE 802.3af/at Compliant power devices (PD)
  • Port Priority Function
  • MAC Address Auto-Learning And Auto-Aging
  • IEEE802.3x Flow Control
Transfer Method
  • Store-And-Forward



OTHERS
Certification
  • FCC, RoHS
Package Contents
  • TL-SG1008MP
  • Power Cord
  • Installation Guide
  • Rackmount Kit
  • Rubber Feet
Consumption
  • 9.5 watts (max. no PD connected)
  • 140.1 watts (max. with 126w PD connected)
Environment
  • Operating Temperature: 0℃~50℃ (32℉~122℉)
  • Storage Temperature: -40℃~70℃ (-40℉~158℉)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing



Product Inquiry

Please send an email to sales@switchcom.co.za for pricing.
